Heavy Duty 3 Tine Round Bale Spear Euro Hitch 1500kg Loader Attachment

Product Overview

The T-RBS13 Heavy Duty 3 Tine Round Bale Spear is a high-capacity Euro hitch loader attachment engineered for operators who need to move more bales in less time. With an adjustable high back option that allows two round or square bales to be carried simultaneously in a single loader pass, this bale spear effectively doubles the productivity of standard single-bale handling setups — making it a practical upgrade for farms, ranches, and feedlots where bale movement is a daily, high-volume task.

The attachment features two main spears, each φ45 mm in diameter, available in either 1,100 mm (approximately 43 inches) or 1,250 mm (approximately 49 inches) lengths to suit different bale sizes and operator preferences. A central stabilizer spear measuring φ36 mm in diameter and 810 mm in length sits between the two main tines to prevent bale rotation and maintain load stability during lifting and transport. The three-tine configuration distributes the load across multiple contact points, reducing stress on individual spears and providing more secure bale engagement compared to single or double-tine alternatives.

One of the most versatile features of this bale spear is the removable centre tine design. The central stabilizer spear can be detached when working with certain bale types or sizes that require a wider gap between the main spears, giving the operator the flexibility to switch between a three-tine and two-tine configuration without tools or additional hardware. This adaptability makes the T-RBS13 effective across a broader range of bale handling scenarios than fixed-tine alternatives.

The frame is built around a welded Conus 2 taper bush mounting system, which provides a secure, play-free connection to Euro hitch front loaders and is compatible with nearly all loader brands and models that use the Euro quick-attach standard. The Conus 2 taper bush design ensures consistent alignment and load transfer between the frame and the loader arm, maintaining structural integrity under the full 1,500 kg safe working load — a rated capacity that exceeds the 1,000 kg limit common among comparable bale spear attachments and provides a meaningful safety margin when handling large, heavy bales.

Weighing between 100 and 103 kg depending on the spear length selected, the T-RBS13 offers a strong strength-to-weight ratio that keeps the attachment manageable for mounting and dismounting while delivering the frame rigidity needed for sustained heavy-duty use. The overall frame dimensions of 1,160 × 1,200 × 900 mm (1,100 mm spear model) or 1,310 × 1,200 × 900 mm (1,250 mm spear model) provide a wide, stable working footprint suited to both field and barn environments.

Details

Features:

·Bale Spike

·Equipped with a welded Conus 2 taper bush for reliable attachment

Specifications:

Technical Drawing:
