Product Overview
The EALITA hydraulic hay bale spear is a heavy-duty loader attachment engineered to safely and efficiently handle single or multiple round and square hay bales during daily feeding, forage transport, and bale stacking operations. Designed for farmers and agricultural operators who demand reliability and flexibility, this hydraulic bale spear delivers stable clamping force, smooth load control, and minimal hay loss — keeping your feeding and forage-handling workflow running efficiently from morning to night.
Equipped with 5 long straight spear tines at φ45×1250mm, this hay spear attachment provides the penetration depth and holding strength needed to securely grip bales of varying sizes and densities without slippage during lifting, transport, or stacking. The multi-tine configuration distributes load evenly across the bale face, reducing the risk of bale damage and ensuring stable, balanced transport even on uneven terrain and slopes.
One of the standout features of this loader bale spear is its fully adjustable design, available with either manual or hydraulic adjustable back frames. This flexibility allows operators to quickly adapt the attachment width and configuration to match different bale sizes, working conditions, and terrain — making it equally effective for shed stacking, field collection, hay stockpiling, and bale transfer tasks without requiring a separate attachment for each job.
At 1800mm wide with a height range of 1800-2400mm and an attachment weight of 365kg, this hydraulic hay spear is built to handle serious bale volumes day in and day out. Whether you are managing a large cattle operation, running a hay contracting business, or simply keeping your farm feeding schedule on track, the EALITA bale spear loader attachment gives you the strength, adjustability, and dependability to handle every bale with confidence.
Details
Features:
·Hydraulic Hay Spear
·Safely handles single or multiple round/square hay bales
·Fully adjustable design, ideal for shed stacking & hay stockpiling
·Available with manual/hydraulic adjustable back frames
·Accommodates up to 5 long spikes for optimal working efficiency
Specifications:
|
Type |
Width(W)/mm |
Height(H)/mm |
Main Spear(La)/mm |
Operating Pressure/MPa |
Hydraulic Flow/LPM |
Attachment |
Weight/kg |
|
W-SHF1500-2400-GEM938 |
1800 |
1800-2400 |
φ45×1250×5 |
16 |
60 |
GEM938 |
365 |
Technical Drawing:
