Product Overview
Self-adjusting suspension allows the sweeper to make minimal adjustments to the ground and to adapt to road changes. Provide best cleaning results with minimal brush wear. Equipped with two powerful, direct-acting hydraulic motors. To provide greater torque and more power to the sweeper, the entire sweeper can be hydraulic rotation of 30 degrees, gravel and debris can be swept to the side.
Details
Features:
·Angle Broom
·Dual direct-acting hydraulic motors for extra torque/power
·30° hydraulic rotation sweeps debris to the side
Specifications:
|
Type |
Sweeping Width (SW)/mm |
Dimension (L×W×H)/mm |
Brush Dia (D)/mm |
Brush Qty. |
Lifting Angle (LA)/° |
Operating Pressure/MPa |
Hydraulic Flow/LPM |
Attachment |
Weight/kg |
|
T-AS3000-BIG BM |
3040 |
3323x1818x1590 |
900 |
67 |
48 |
16 |
60 |
BIG BM |
727 |
Technical Drawing:
