Product Overview
The Skid Steer Leveling Bar is a versatile and heavy-duty grading attachment designed to handle a wide range of outdoor tasks with precision and efficiency. Whether you are finish grading a construction site, spreading landscape supplies, backfilling trenches, or breaking up compacted turf, this leveling bar delivers consistent, professional results across every application. Compatible with most skid steer loaders and compact track loaders via a universal quick-attach system, it is built to become one of the most frequently used attachments in your equipment lineup.
Engineered from heavy-duty steel with a robust working frame, this leveling bar is built to withstand the demands of daily use in tough job site conditions. The wide 44 inch (1120mm) working width allows operators to cover large areas quickly, reducing the number of passes needed to complete grading and spreading tasks and significantly improving overall job site productivity. The sturdy cutting edge bites into the ground with consistent depth and control, giving operators the precision needed for smooth, even finish grading results.
This leveling bar excels at hauling and redistributing job site materials such as gravel, topsoil, mulch, and fill dirt across uneven surfaces. Its design allows operators to push, pull, and spread material in a single pass, making it ideal for landscape supply spreading, driveway grading, and general site preparation work. The attachment also performs exceptionally well when backfilling trenches, allowing operators to efficiently move and compact loose material back into excavated areas without the need for additional equipment.
For operators working in turf and agricultural environments, this leveling bar is equally effective at breaking up tough, compacted turf and preparing ground for seeding, sodding, or landscaping. The combination of its wide working width and heavy-duty cutting edge makes it a practical tool for farm lane maintenance, paddock leveling, and rural property grading tasks where a dedicated grader or box blade would be impractical or cost-prohibitive.
Available in two sizes — 44 inch (1120mm) with a weight of 90kg, and a larger 44 inch (1207mm) variant weighing 119kg — this leveling bar offers flexibility to match different machine capacities and job site requirements. If you need a single skid steer attachment that can grade, spread, backfill, haul, and level with equal capability, the Skid Steer Leveling Bar is the multi-purpose grading solution built to deliver professional results every time.
Details
Features:
·Leveling Bar
Specifications:
|
Type |
Width(W)/mm |
Depth(D)/mm |
Height(H)/mm |
Mount Plate |
Weight/kg |
|
CS-LB1120(44IN)-MP910 |
1120 |
1090 |
480 |
MP910 |
90 |
|
CS-LB1200(44IN)-MT100 |
1207 |
1035 |
603 |
MT100 |
119 |
Technical Drawing:
