Manual Quick Hitch for Excavators E-MQC

The Manual Quick Hitch is used with Mini Diggers / Excavators to allow the rapid and efficient change of buckets and attachments.

Type:
E-MQC
Surface Treatment:
Black Painting or As Request

Product Details

The Manual Quick Hitch is used with Mini Diggers / Excavators to allow the rapid and efficient change of buckets and attachments. It removes the requirement to manually drive pins in and out.

Full series includes E-MQC30,E-MQC40,E-MQC50,E-MQC60,E-MQC70.

Available for 0.75 - 3 Ton Excavators

Type	Length(L)/mm	Width(W)/mm	Height(H)/mm	Axle Base(A)/mm	Weight/kg	Suit Excavator/T
E-MQC30	384	202	215	230.5	31	1-2
E-MQC40	450	234	241	300.5	43	2-3.5
E-MQC50	612	312	271	430.5	71	6-8
E-MQC60	616	392	327	480.5	114	10-14
E-MQC70	796	512	396	600.5	179	16-18

Combining strength, durability and safety this hitch contains a number of features which minimise the risk of harm being caused during operation. These include:

• Hi-vis Latch gives clear visibility when latch is engaged
• Captive safety pin prevents it getting lost or damaged

Height(H)/mmWeight/kg
