Product Overview
The power is supplied by hydraulic direct drive motor. Supply with two 10mm thickness Wear-resistant high-strength cutting blade. Gear box turns the blades at around 1100 RPM's with 75L per min flow, for a very efficient cut.
The deck is equipped with a stump jumper between the blades and the deck, to help ride over obstacles like stumps.
Details
Features:
·Brush Cutter
·Hydraulic direct drive motor power
·Stump jumper fitted for obstacle crossing
Specifications:
|
Type |
Dimension(WDH)/mm |
Working Width(Dw)/mm |
Blade Width(Wb)/mm |
Blade Thickness/mm |
Operating Pressure/MPa |
Hydraulic Flow/LPM |
Weight/kg |
|
S-BC1650(65IN)-MP1140 |
1650×1709×591 |
1480 |
78 |
10 |
18 |
75 |
409 |
|
S-BC1830(72IN)-MP1140 |
1830×1869×591 |
1620 |
78 |
10 |
18 |
75 |
488 |
Technical Drawing:
Scene graph:
